ECO-PANEL


FEATURES


· Vari-Panel:Eco 100lm/w;
· Panel:40W,3500LM;
· Size:60*60,62*62,30*30,30*60cm,white frame;

·Option:UGR<19 available,Emergency kit.

·Driver:No flicker,DALI,0-10V.




TECHNICAL PARAMETERS

Ref.No

Panel rated Wattage(W) included driver
Dimension(mm)
Panel Input current(mA)
Panel Input wattage(w) wtihout driver

**Efficiency(lm/w)

**Lumen(lm)

Standard CC

T(K)

CR

I(Ra)

NS-PLS-6060XX
40
595*595*7.5
1000
35
95/100/115
2300/3600/4000
3000/4000/6000
>80
NS-PLS-6262XX
40
620*620*7.5
1000
35
95/100/115
2300/3600/4000
3000/4000/6000
>80
NS-PLS-30120XX
40
295*1195*7.5
1000
35
105
3600
3000/4000/6000
>80

DIMENSIONS/UNIT(mm):
